Introduction
Smart RFID Cabinet is designed for management and control of valuable items requiring special access protocols such as:
Medical consumables: stents, cardiovascular catheters, etc.
Jewelry: diamonds, gold, etc.
Special designed biometric measure (finger vein) allows access to the cabinet even with gloves on (medical nitrile, latex gloves). Built-in UPS allows maintaining locking state at power failures.
Leading Technology
Powered by leading BoundField Technology the smart cabinet ensures 100% accuracy & 200 tags/second fast reading; and in the meantime, with build-in access control technologies:
RFID Card (badge)
Finger Vein Recognition (working even wearing latex/vinyl gloves)
Facial Recognition (optional)
Benefits
Restricted access to high cost consumables and avoiding material losses.
Produce accurate inventory records in real time
Eliminate stock-outs and expired items
Eliminate costly inventory waste (right-size inventory) and expired consumables
Eliminate hospital supply disputes over quantities consumed
Save time for medics on patient care
Advantages
No missing tag problems: all tags in the cabinet will be read without missing
No stray/unwanted reads: only tags in the cabinet will be read; tags passing by the cabinet will Not be read
No tag-collision problems: no tag collision caused missing-tags for 300+ tags in cabinet
Fast reading: 200pcs/second reading speed to count the items in the cabinet within 5 seconds
Multi-antenna design: multi antennas ensure all tags will be read
Transparent doors: tempered glass doors provides visibility of items inside the cabinet without stray/unwanted reads
Open API for connection to ERP or HIS system, etc.
Finger vein recognition for convenient access clearance when wearing gloves
Secure locking system with UPS ensures safety of items in cabinet at power failure
Adjustable shelves allow the height of each shelf and the spacers on every shelf can be adjusted freely
Up to 8 subordinate cabinets can be connected to 1 master cabinet
Master Cabinet Technical Specifications
Parameters (Master Cabinet) | |
Dimensions (mm) | L790 x W560 x H1880 |
Frequency Range | 902MHz ~ 928MHz; 865MHz~868MHz |
Communication Interface | Lan, Bluetooth, Ethernet |
Working Temperature | -15°C ~ +45°C |
Data Format | ISO 18000-6C protocol |
Screen | 21” CTP touch screen, 1920x1080 resolution RAM 2GB FLASH 16GB |
Product Characteristics
Multiple verifications (Digital vein, Face ID, ID badge)
Fast and accurate identification (200 tags per second)
Free combination of 1 master cabinet and 1-8 subordinate cabinets
Self-locking after power failure
Multi system docking
Application
High-value Consumables Management
High-value products management in hospitals. The cabinet will store product information automatically in the inventory system, and avoid any human error.
Drug Control
Track and manage of controlled drugs. Only authorized personnel can open the cabinet for drugs and relevant use records will be upload to the control system.
